TP-Link 24-Port Gigabit Easy Smart Switch

TL-SG1024DE

24 10/100/1000Mbps RJ45 ports
Provides network monitoring, traffic prioritization and VLAN features
Innovative energy-efficient technology reduces power output by up to 40%
Simple network set-up on top of plug-and-play connectivity

HARDWARE FEATURES
Standards and Protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Interface	24 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX
Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
Dimensions (W X D X H)	11.67.11.7 in. (29418044 mm)
Fan Quantity	Fanless
Power Supply	100-240VAC, 50/60Hz
PERFORMANCE
Switching Capacity	48Gbps
MAC Address Table	8K
Packet Buffer Memory	512KB
Packet Forwarding Rate	35.7Mpps
Jumbo Frame	10240Bytes
SOFTWARE FEATURES
Quality of Service	Support Port Based/802.1p Based priority Support 4 priority queues Rate Limit Storm Control
L2 Features	IGMP Snooping Link Aggregation Port Mirroring Cable Diagnostics Loop Prevention
VLAN	Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs) MTU/Port/Tag VLAN
Transmission Method	Store-And-Forward
OTHERS
Certification	FCC, CE
Package Contents	TL-SG1024DE, Power Cord, Installation Guide, Resource CD, Rackmount Kit, Rubber Feet
System Requirements	Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ Windows 7 or Windows 8, MAC® OS, NetWare®, UNIX® or Linux.
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
