CBN CD8000 DOCSIS 3.1 Data Modem

CBN CD8000 DOCSIS 3.1 Data Modem

CBN DOCSIS 3.1 Data Modem (Rogers Certified)

support  – Rogers/Cogeco/Shaw/ Videotron

CD8000 DOCSIS 3.1, 32×8 cable modem, 2 x Gigabit Ethernet LAN. Note: For use with TPIA ISPs on the Rogers and Shaw cable networks. TPIA Internet Service Providers are third parties who activate customers on the Rogers and Shaw networks, while customers billed directly by Rogers and Shaw cannot purchase this modem.

FEATURES
DOCSIS 3.1 and DOCSIS 3.0 compliant
2×2 OFDM/OFDMA and 32×8 SCQAM channel bonding
Full spectrum capture tuner
Switchable upstream 5 42Mhz or 5 85 MHz and
108
1218MHz downstream
Supports IPv4 and IPv6
Multiple L2VPN BSoD support with OAM extensions
2 port auto sensing Gigabit Ethernet
Easy Setup and installation
Web based GUI control configuration and management
CBN proprietary MIBs for extended support on DOCSIS

PRODUCT OVERVIEW
The Compliance Broadband Networks’ CD8000 Cable Data Modem that is DOCSIS 3.1
and DOCSIS 3.0
and easy Setup and installation. Especially for your home entertainment such like 4K Ultra HD
video streaming and gaming for best by using two 1 Gigabit Ethernet ports! CD8000 able give
you fastest speeds and most reliable connection to the internet.

CD8000
DOCSIS 3.1 Data Modem
Specification
Interfaces  RF F Type 75 female connector
 2 port auto sensing Gigabit Ethernet RJ 45
Key Features  DOCSIS 3.1 and DOCSIS 3.0 compliant
2×2 OFDM/OFDMA and 32×8 SCQAM channel bonding
Full spectrum capture tuner
Switchable upstream filters for 42MHz/85MHz
Switchable downstream filter for 108MHz to upper edge of 1218MHz
Supports IPv4 and IPv6 and L2VPN BSoD
Easy Setup and installation
Web based GUI control configuration and management
CBN proprietary MIBs for extended support on DOCSIS
Data Rate (Mbps Max.)
Over 2 Gbps
Compliance  FCC, Industrial Canada, RoHS, FCC, CE and WEEE , UL/cUL
LED s Front  Integrated LEDs for status of P ower, Uplink, Downlink, Internet
LED s Rear  Ethernet Link/Active
Dimension
13 4 mm (H) x 13 2 mm (D) x 43 mm (
Environmental  Operating temperature: 0°C  to  40°C
Operating relative humidity: 5 %  – 85 % (non condensing)
Storage temperature: – 40°C  -70°C
